The Cisco Aironet 1832i Access Point, model AIR-AP1832I-Q-K9, stands out for its implementation of the latest 802.11ac Wave 2 standard, which provides high-speed Wi-Fi connectivity and is essential for today’s mobile-centric workforce. The 3×3 MIMO technology ensures optimal coverage and reliability for simultaneous data transmission to multiple devices, which is a significant improvement over Wave 1 and older Wi-Fi standards. With speed capabilities of up to 867 Mbps, the network bandwidth can easily support video conferencing, large file transfers, and other bandwidth-intensive tasks without interruption.
Installing the Aironet 1832i can greatly increase productivity by addressing the growing demands for wireless bandwidth due to the increasing number of Wi-Fi connected devices. Its compatibility with Power over Ethernet (PoE) makes for easy installation and reduces the need for additional power cables, enhancing workplace safety and simplicity.
Security is another cornerstone of the Cisco Aironet 1832i, with robust features designed to protect sensitive corporate information. The Q Regulatory Domain ensures that the device operates using the allowed frequencies and channels in particular geographical areas, providing legal compliance and efficient spectrum usage.
Additionally, the sleek design and internal antennas of the AIR-AP1832I-Q-K9 minimize physical space requirements, blending seamlessly into professional environments while providing 360° wireless coverage. This device offers backward compatibility, which means it works with older Wi-Fi standards devices while preparing the network infrastructure for future technology advancements.
By purchasing the Cisco Aironet 1832i, you are investing in a secure, high-speed, and reliable wireless space that will support the current and next generation of Wi-Fi devices, thus future-proofing your network for years to come.
AIR-AP1832I-Q-K9 is one of the Cisco Aironet 1830 Series Access Points. Cisco 1830 AP series is ideal for small and medium-sized networks. This series supports the latest Wi-Fi standard, the 802.11ac Wave 2 standard. The 1830 Series extends support to a new generation of Wi-Fi clients, such as smartphones, tablets, and high-performance laptops that have integrated 802.11ac Wave 1 or Wave 2 support. The model AIR-AP1832I-Q-K9 provides Q Regulatory Domain and internal antennas.
Quick Specs
Table 1 shows the quick specs of AIR-AP1832I-Q-K9.
|
Part Number |
AIR-AP1832I-Q-K9 |
|
Description |
802.11ac Wave 2 AP, 3×3:2, Internal Antenna, Q Regulatory Domain |
|
Features |
– 3×3 MIMO with two spatial streams, single-user or multiuser MIMO – MRC – 802.11ac beamforming (transmit beamforming) – 20-, 40-, and 80-MHz channels – PHY data rates up to 867 Mbps (80 MHz in 5 GHz) – Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) – 802.11 DFS – CSD support |
|
Regulatory Domain |
Q (Q regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.180 to 5.320 GHz; 8 channels – 5.500 to 5.700 GHz; 11 channels |
|
Integrated antenna |
– 2.4 GHz, gain 3 dBi, internal omni, horizontal beamwidth 360° – 5 GHz, gain 5 dBi, internal omni, horizontal beamwidth 360° |
|
Interfaces |
– 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE) – Management console port (RJ-45) – USB 2.0 (enabled via future software) |
|
Dimensions (W x L x H) |
8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) |
|
Weight |
3.12 lb (1.41 kg) |
Product Details
Figure 1 shows the AIR-AP1832I LED Indicator Position.
Note: â‘ LED indicator position
Table 2 shows the AP LED indicators’ descriptions.
|
Message Type |
LED State |
Message Meaning |
|
Association status |
Chirping Green |
Normal operating condition, but no wireless client associated |
|
Green |
Normal operating condition, at least one wireless client association |
|
|
Boot loader status |
Green |
Executing boot loader |
|
Boot loader error |
Red |
Boot loader signing verification failure |
|
Access point regulatory domain priming status |
Blinking Amber |
AP priming to a new regulatory domain by Neighbor Discovery Protocol (NDP), in progress |
|
Cycling Red, Green and off |
AP waiting to be primed |
|
|
Chirping Red |
AP primed to a wrong regulatory domain |
|
|
Operating status |
Blinking amber |
Software upgrade in progress |
|
Cycling through green, red, and amber |
Discovery/join process in progress |
|
|
Rapidly cycling through red, green, amber, and off. |
Access point location command invoked from controller web interface. |
|
|
Access point operating system errors |
Cycling through red, green, amber, and off |
General warning; insufficient inline power |
Figure 2 shows AIR-AP1832I Ports and Connections.
Note:
|
â‘ |
Mode button |
â‘£ |
PoE-In port (Ethernet Uplink port) |
|
â‘¡ |
RJ-45 console port |
⑤ |
48 V DC input power port |
|
â‘¢ |
USB 2.0 port |
Compare to Similar Items
Table 3 shows the comparison between two AP.
|
Part Number |
AIR-AP1832I-Q-K9 |
AIR-AP1832I-Q-K9C |
|
Description |
802.11ac Wave 2 AP, 3×3:2 |
802.11ac Wave 2 AP, 3×3:2 ★ Model number ending in C is, by default, factory-shipped with a Cisco Mobility Express software image. |
|
Integrated antenna |
Yes |
Yes |
|
Regulatory Domain |
Q (Q regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.180 to 5.320 GHz; 8 channels – 5.500 to 5.700 GHz; 11 channels |
Q (Q regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.180 to 5.320 GHz; 8 channels – 5.500 to 5.700 GHz; 11 channels |
Support & Resources
[PDF] Cisco Indoor Access Points Comparison Chart
Get more information
Do you have any question about the AIR-AP1832I-Q-K9?
Contact us now via Contact Form or sales@northlandusa.com.
Affordability and Quality of Cisco Aironet 1832i
Purchasing the AIR-AP1832I-Q-K9 – Cisco Aironet 1832i Access Point at Northland Systems ensures a balance between affordability and outstanding quality. With a 100% Low Price Guarantee, the product offers exceptional functionality at wholesale rates. The commitment to delivering premium network equipment without financial strain is a cornerstone of Northland Systems.
Free Expert Support Availability
Northland Systems provides free expert technical support, making the installation and management of Cisco Aironet 1832i simpler. Customers receive guidance from CCIE certified professionals across multiple channels, thereby elevating the customer service experience without any additional expenses.
Transaction Security and Flexibility
The safety and convenience of customer transactions are paramount at Northland Systems. With secure payment options and flexible shipping methods, backed by McAfee Secure and VeriSign Secured certifications, customers can transact with confidence when purchasing wireless indoor access points.
Guarantee on Product Authenticity and Condition
Every Cisco 1800 Access Point sold, including the AIR-AP1832I-Q-K9, is original and genuine. Customers can choose from ‘New Sealed’ or ‘Used / Refurbished’ units, each rigorously examined and tested by Cisco-certified engineers to ensure optimum reliability and performance for 802.11ac Wave 2 Access Points.
Building Customer Confidence
Northland Systems backs up its commitment to trust and customer satisfaction with a 100% Money Back Guarantee on equipment like the Cisco Aironet 1832i, solidifying the assurance buyers need when investing in top-grade networking hardware.
Renowned Reputation and Discounts
Since its inception in 1997, Northland Systems has offered substantial discounts across a wide range of networking equipment. Their long-standing reputation in the industry is complemented by reduced prices, making premium products like the Cisco Aironet 1832i Access Point economically accessible.
Choosing Pre-owned Hardware Benefits
- Substantial cost savings on high-quality equipment.
- Quicker delivery options to meet urgent needs.
- Environmental sustainability through reused and recycled technology.
- Continued access to legacy models that ensure system compatibility.
- Full warranty coverage providing peace of mind.
Consider the AIR-AP1832I-Q-K9 – Cisco Aironet 1832i Access Point for a blend of performance, reliability, and sustainability from Northland Systems.
