The Cisco Catalyst WS-C3650-24PD-L is a cutting-edge network switch that delivers several key advantages for any business or high-demand network environment. As part of Cisco’s reputable Catalyst 3650 series, this switch allows for seamless integration of wired and wireless networks, enhancing efficiency and ensuring a consistent user experience across the network. With 24 POE+ Ethernet ports, this switch simplifies the deployment of IP cameras, VoIP phones, and wireless access points by delivering power and data over a single cable.
Ideal for mid-sized to large enterprise operations, the switch features two 10G SFP+ or four 1G SFP uplink ports, providing high-bandwidth uplink capabilities for faster data transfer and support for stack growth. The stack-wise technology, which allows you to stack up to 9 switches, optimizes scalability while increasing redundancy; if one switch fails, another one in the stack will automatically take over, reducing downtime and business impacts.
The forwarding performance and switching capacity, 68.45 Mpps and 88 Gbps respectively, ensure that data flows quickly and efficiently through the network. With this level of performance, the WS-C3650-24PD-L can handle a large volume of network traffic and is capable of providing services such as QoS and network-wide VLANs, improving overall network management.
Moreover, network security is a critical component, and the WS-C3650-24PD-L includes robust security features to protect your data. Security measures such as access control lists (ACLs), guest VLANs, and IEEE 802.1X support guard against unwelcome access and potential threats.
Buying the Cisco WS-C3650-24PD-L means investing in reliability. Cisco’s reputation for durable and dependable products is well recognized, promising that this switch will function as the backbone of your network infrastructure for years to come. With a feature set designed to meet the needs of modern networking, the Catalyst WS-C3650-24PD-L is an investment in your organization’s technological future.
The Cisco Catalyst 3650 Series Switch, with Cisco StackWise-160 Technology, can stack 9 switches and support up to 160 Gpbs stack bandwidth. The WS-C3650-24PD-L integrates with 24 POE+ Ethernet ports and 2 x 10G SFP+ or 4 x 1G SFP uplink ports in LAN base feature set.
Quick Specs
Figure 1 shows the appearance of WS-C3650-24PD-L.
Table 1 shows the Quick Specs.
| Product Code | WS-C3650-24PD-L |
| Enclosure Type | Rack-mountable – 1U |
| Feature Set | LAN base |
| Uplink Interfaces | 2 x 10G SFP+ or 4 x 1G SFP |
| Ports | 24 x 10/100/1000 POE+ Ethernet ports |
| Available PoE Power | 390W |
| Maximum stacking number | 9 |
| Stack bandwidth | 160 Gpbs |
| Forwarding Performance | 68.45Mpps |
| Switching Capacity | 88 Gbps |
| RAM | 4 G |
| Flash Memory | 2 G |
| Number of AP per switch/stack | 50 |
| Number of wireless clients per switch/stack | 1000 |
| Dimensions | 44.5 cm x 44.8 cm x 4.4 cm |
| Package Weight | 17.49 Kg |
Product Details
Figure 2 shows the front panel of WS-C3650-24PD-L.
Note:
① Mode button ② Status LEDs ③ USB mini-Type B (console) port ④ USB Type A storage port ⑤ 24 x 10/100/1000 POE+ Ethernet Ports
⑥ 2 x 10G SFP+ or 4 x 1G SFP Uplink ports
Figure 3 shows the back panel of the Cisco C3650-24PD-L switch.
Note：
① Ground connector ② CONSOLE (RJ-45 console port) ③ MGMT (RJ-45 10/100/1000 management port) ④ Fan module ⑤ Power supply modules
Figure 4 shows the StackWise-160 Kit.
The Cisco Catalyst 3650 supports an optional stacking module that is based on the Cisco StackWise-160 technology which allows stacking up to 9 switches.
The Modules, Licenses and Accessories
Table 2 shows some recommended modules,licenses and accessories of this switch.
| Models | Description |
| C3650-STACK-KIT | Cisco Catalyst 3650 Stack Module Spare |
| L-C3650-24-L-E= | C3650-24 LAN Base to IP Services Electronic RTU License |
| L-C3650-24-L-S= | C3650-24 LAN Base to IP Base Electronic RTU License |
| PWR-C2-640WAC= | 640W AC Config 2 Secondary Power Supply |
| CAB-CONSOLE-RJ45 | Console Cable 6ft with RJ45 and DB9F |
| CAB-CONSOLE-USB | Console Cable 6 ft with USB Type A and mini-B |
Compare to Similar Items
| Models | WS-C3650-24PD-L | WS-C3650-24TD-L |
| Feature Set | LAN Base | LAN Base |
| Uplink Interfaces | 2 * 10G SFP+ OR 4 * 1G SFP uplinks | 2 * 10G SFP+ OR 4 * 1G SFP uplinks |
| Ports | 24 * 10/100/1000 POE+ Ethernet ports | 24 * 10/100/1000 Ethernet ports |
| Available POE Power | 390W | N/A |
