Opt for Cisco’s WS-C2960XR-48LPS-I for effective network management and expansion. Its dual power supplies enhance reliability for mission-critical environments, preventing downtime. IP Lite IOS enables advanced Layer 3 routing necessary for efficient network traffic management. PoE+ capability with a substantial power budget enhances deployment flexibility, allowing for devices like VoIP phones or wireless access points without additional wiring. High-capacity uplinks ensure smooth traffic handling even in demanding data environments. With energy-efficient design, it reduces operational costs and supports network sustainability. Its scalability with stack capability guarantees future growth needs are met, preserving your investment over time.
Cisco Catalyst 2960-XR series switches offer power resiliency with optional dual field-replaceable power supplies and IP Lite Cisco IOS software with dynamic routing and Layer 3 features. WS-C2960XR-48LPS-I is one of 2960-XR switches, IP Lite switch, supporting forty-eight 10/100/1000 Ethernet ports with POE+ and 4 x 1G SFP uplink interfaces. IP Lite Image enables basic access layer 3 routing features, such as RIPV1, V2, OSPF stub, EIGRP stub, HSRP, VRRP, PIM stub, etc.
Quick Specs
Table 1 shows the Quick Specs.
Product Code |
WS-C2960XR-48LPS-I |
Enclosure Type |
Rack-mountable – 1U |
Feature Set |
IP Lite |
Uplink Interfaces |
4 x 1G SFP |
Ports |
48 x 10/100/1000 (POE+) |
Available PoE Power |
370W |
Forwarding Bandwidth |
108Gbps |
Maximum stacking number |
8 |
Stack bandwidth |
80G |
Switching Bandwidth |
216Gbps |
RAM |
512 MB |
Flash Memory |
128 MB |
Dimensions |
44.5 cm x 40.8 cm x 4.45 cm |
Package Weight |
16.15 Kg |
Product Details
Figure 1 shows the front panel of WS-C2960XR-48LPS-I.
Note:
·There are Forty-eight 10/100/1000 Ethernet Gigabit Ports and four 1G SFP uplink Ports on the front panel.
·Two USB Type A ports and one USB mini-Type B (console) port are on the left.
·This switch offers one RJ-45 console port and one Ethernet management port on the left of the front panel.
·Power over Ethernet Plus(PoE+) supports up to 370W of PoE budget for 12 ports with 30W per port or 24 ports with 15.4W per port or 48 ports with 7.4W per port.
Figure 2 shows the back panel of WS-C2960XR-48LPS-I.
Note:
â‘ FlexStack-Plus module slot and cover â‘¡ Power supply slot (with blank module) â‘¢ AC OK LED â‘£ PS OK LED
⑤ AC power connector on the power supply module
The WS-C2960XR-48LPS-I supports stacking with the optional stack kit. It has the FlexStack-Plus module (hot-swappable) that inserts in the slot located in the switch rear panel, and a 0.5-meter FlexStack cable to connect the FlexStack-Plus module ports. The stack module should purchase separately.
The Accessories
Table 2 shows some accessories of WS-C2960XR-48LPS-I.
Models |
Description |
C2960X-STACK |
Catalyst 2960-X FlexStack Plus Stacking Module |
CAB-STK-E-0.5M |
Cisco FlexStack Stacking Cables |
GLC-LH-SMD |
Cisco GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
GLC-SX-MMD |
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
CAB-CONSOLE-RJ45 |
Console Cable 6ft with RJ45 and DB9F |
CAB-CONSOLE-USB |
Console Cable 6 ft with USB Type A and mini-B |
Get more information
Do you have any question about the Cisco Catalyst 2960XR-48LPS-I switch?
Contact us now via Contact Form or sales@northlandusa.com.
