The Cisco Nexus 9372TX (N9K-C9372TX) is pivotal for modern data centers seeking agility, high-performance, and reliability. Equipped with 48 10Gbps BASE-T and 6 40Gbps QSFP+ ports, the switch addresses high-density networking requirements crucial for large-scale operations. With a throughput of 1.44 Tbps, the N9K-C9372TX ensures swift data transfer, making it a powerhouse for bandwidth-intensive applications.
Energy efficiency is another cornerstone of the Nexus 9372TX. It delivers optimal performance per watt, reducing operational costs and supporting eco-friendly practices. Moreover, the switch has up to two power supplies, enabling redundancy and flexibility consistent with various energy sources, ensuring uninterrupted operations.
Scalability is a defining trait. Whether you’re expanding a data center or integrating new services, the switch scales with your business, preventing bottlenecks and fostering uninterrupted growth. The additional packet buffer space per port bolsters this capability, accommodating traffic burst without sacrificing performance. Network resilience is thereby enhanced, contributing to more robust service delivery.
Cisco’s NX-OS and ACI compatibility introduces automation and simplified management, reducing the complexity of network operations. Advanced features provide centralized control, streamline maintenance tasks, and accelerate deployment of applications and services.
For organizations prioritizing both future-proofing their network infrastructure and operational efficiency, investing in the Cisco Nexus 9372TX is strategic. It solidifies network foundations in an era where data throughput and steady connectivity are paramount for success. With a feature set designed to meet and exceed modern data center demands, the Cisco Nexus 9372TX emerges as a leading solution for ensuring that your network is not only operational but optimized for the challenges of today and tomorrow.
Cisco Nexus 9372TX Switch（N9K-C9372TX） is a 1RU switch that supports 1.44 Tbps of bandwidth and over 1150 mpps across 48 fixed 10-Gbps BASE-T ports and 6 fixed 40-Gbps QSFP+ ports.
Quick Specs
Figure 1 shows the appearance of N9K-C9372TX.
Table 1 shows the Quick Specs.
|
Product Code |
N9K-C9372TX |
|
Ports |
48 fixed 1/10GBASE-T and 6 QSFP+ ports |
|
Form factor |
1 RU |
|
Throughput (Tbps) |
1.44 |
|
Supported speeds |
100 Megabit Ethernet and 1/10 Gigabit Ethernet speeds |
|
40 Gigabit Ethernet uplink port |
6 fixed QSFP+ ports ·Advanced QSFP+ optics enable connectivity using existing 10 Gigabit Ethernet fiber. |
|
Power supplies (up to 2) |
650W AC, 930W DC, or 1200W HVAC/HVDC |
|
Typical power(AC & DC) |
374.5W |
|
Maximum power(AC & DC) |
694W |
|
Maximum number of longest prefix match (LPM) routes |
128,000 |
|
CPU, SSD, and memory |
Dual-core 2.5-GHz x86 CPUs with 64-GB SSD drive and 16 GB of memory provide enhanced network performance |
|
Buffer (MB) |
37 |
|
Operating System |
NX-OS, ACI |
|
Fans |
4 |
|
Physical (H x W x D) |
1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1cm) |
|
Acoustics |
48.6 dBA at 40% fan speed, 65.2 dBA at 70% fan speed, and 76.5 dB at 100% fan speed |
|
Weight（without power supplies or fans） |
22.6 lb (10.25 kg) |
·Typical and maximum power values are based on input drawn from the power circuit. The power supply value (for example, 650W AC power supply: N9K-PAC-650W) is based on the output rating to the inside of the switch.
·The actual maximum scale depends on the system forwarding mode
Product Details
Figure 2 shows the front panel of N9K-C9372TX.
Note:
|
â‘ |
Beacon (BCN), Status (STS), and Environment (ENV) LEDs |
|
â‘¡ |
10GBASE-T APIC-facing ports (48) supporting 100-Megabit, 1-Gigabit, and 10-Gigabit Ethernet |
|
â‘¢ |
40-Gigabit QSFP+ spine-facing ports (6) supporting 10- and 40-Gigabit Ethernet |
The Accessories
Table 2 shows the recommended elements for the N9K-C9372TX.
|
Category |
Model |
Description |
|
40G Transceiver and Cable Options
|
QSFP-H40G-ACU10M |
Cisco QSFP to QSFP copper direct-attach 40GBASE-CR4 cable QSFP-H40G-ACU10M |
|
QSFP-H40G-CU1M |
Cisco QSFP to QSFP copper direct-attach 40GBASE-CR4 cable QSFP-H40G-CU1M |
|
|
QSFP-H40G-CU3M |
Cisco QSFP to QSFP copper direct-attach 40GBASE-CR4 cable QSFP-H40G-CU3M |
|
|
QSFP-H40G-CU5M |
Cisco QSFP to QSFP copper direct-attach 40GBASE-CR4 cable QSFP-H40G-CU5M |
Compare to Similar Items
Table 3 shows the comparison of the N9K-C9372TX and N9K-C9372PX.
|
Product Code |
N9K-C9372TX |
N9K-C9372PX |
|
Ports |
48 fixed 1/10GBASE-T and 6 QSFP+ ports |
48 fixed 1/10GBASE-T and 6 QSFP+ ports |
|
Form factor |
1 RU |
1 RU |
|
Throughput (Tbps) |
1.44 |
1.44 |
|
Supported speeds |
100 Megabit Ethernet and 1/10 Gigabit Ethernet speeds |
1/10 Gigabit Ethernet speeds |
|
Typical power(AC & DC) |
374.5W |
210W |
|
Maximum power(AC & DC) |
694W |
537W |
|
Maximum number of longest prefix match (LPM) routes |
128,000 |
128,000 |
|
Acoustics |
48.6 dBA at 40% fan speed, 65.2 dBA at 70% fan speed, and 76.5 dB at 100% fan speed |
48.5 dBA at 40% fan speed, 64.9 dBA at 70% fan speed, and 77.8 dB at 100% fan speed |
|
Weight（without power supplies or fans） |
22.6 lb (10.25 kg) |
22.2 lb (10.1 kg) |
