Choosing the Cisco Aironet 1832i Access Point AIRAP1832I-HK910C is a savvy move for businesses seeking to modernize their Wi-Fi infrastructure. This access point is designed to meet the demands of today’s mobile-heavy environment by providing robust 802.11ac Wave 2 standard support and a 3×3 MIMO configuration that accelerates the wireless network to new heights, with PHY data rates up to 867 Mbps. The internal antennas maintain an omnidirectional signal pattern, ensuring pervasive coverage throughout your premises.
Its integration with Cisco Mobility Express makes deployment straightforward, eliminating the need for extensive IT knowledge. The pack of 10 allows for widespread coverage and ensures connectivity across larger areas without sacrificing performance. Additionally, PoE support simplifies installation by minimizing the need for additional power sources and wiring, thereby reducing deployment costs and complexities.
The Cisco Aironet 1832i also comes equipped with 802.11 DFS and CSD support to navigate crowded airwaves and improve airtime fairness, ensuring that all clients receive adequate bandwidth. With its built-in security features, your network is safeguarded against threats, providing peace of mind and compliance with business security protocols.
Employing a future-proof solution like the AIRAP1832I-HK910C positions your network to handle upcoming devices and applications that will inevitably demand more bandwidth and faster speeds. Investing in Cisco’s reliable technology ensures that your wireless network infrastructure will remain robust and resilient, delivering a seamless Wi-Fi experience that drives increased productivity and satisfaction for users throughout your organization.
AIRAP1832I-HK910C is one of the Cisco Aironet 1830 Series Access Points. Cisco 1830 AP series is ideal for small and medium-sized networks. This series supports the latest Wi-Fi standard, the 802.11ac Wave 2 standard. The 1830 Series extends support to a new generation of Wi-Fi clients, such as smartphones, tablets, and high-performance laptops that have integrated 802.11ac Wave 1 or Wave 2 support. The model AIRAP1832I-HK910C provides H Regulatory Domain and internal antennas. It provides 10-pack with Mobility Express. Model number ending in C is, by default, factory-shipped with a Cisco Mobility Express software image.
Quick Specs
Table 1 shows the quick specs of AIRAP1832I-HK910C.
|
Part Number |
AIRAP1832I-HK910C |
|
Description |
Cisco Aironet 1830 Series 10-pack with Mobility Express, 802.11ac Wave 2 AP, 3×3:2, Internal Antenna, H Regulatory Domain ★ Model number ending in C is, by default, factory-shipped with a Cisco Mobility Express software image. |
|
Features |
– 3×3 MIMO with two spatial streams, single-user or multiuser MIMO – MRC – 802.11ac beamforming (transmit beamforming) – 20-, 40-, and 80-MHz channels – PHY data rates up to 867 Mbps (80 MHz in 5 GHz) – Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) – 802.11 DFS – CSD support |
|
Regulatory Domain |
H (H regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.150 to 5.350 GHz; 8 channels – 5.745 to 5.825 GHz; 5 channels |
|
Integrated antenna |
– 2.4 GHz, gain 3 dBi, internal omni, horizontal beamwidth 360° – 5 GHz, gain 5 dBi, internal omni, horizontal beamwidth 360° |
|
Interfaces |
– 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE) – Management console port (RJ-45) – USB 2.0 (enabled via future software) |
|
Dimensions (W x L x H) |
8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) |
|
Weight |
3.12 lb (1.41 kg) |
Product Details
Figure 1 shows the AIR-AP1832I LED Indicator Position.
Note: ① LED indicator position
Table 2 shows the AP LED indicators’ descriptions.
|
Message Type |
LED State |
Message Meaning |
|
Association status |
Chirping Green |
Normal operating condition, but no wireless client associated |
|
Green |
Normal operating condition, at least one wireless client association |
|
|
Boot loader status |
Green |
Executing boot loader |
|
Boot loader error |
Red |
Boot loader signing verification failure |
|
Access point regulatory domain priming status |
Blinking Amber |
AP priming to a new regulatory domain by Neighbor Discovery Protocol (NDP), in progress |
|
Cycling Red, Green and off |
AP waiting to be primed |
|
|
Chirping Red |
AP primed to a wrong regulatory domain |
|
|
Operating status |
Blinking amber |
Software upgrade in progress |
|
Cycling through green, red, and amber |
Discovery/join process in progress |
|
|
Rapidly cycling through red, green, amber, and off. |
Access point location command invoked from controller web interface. |
|
|
Access point operating system errors |
Cycling through red, green, amber, and off |
General warning; insufficient inline power |
Figure 2 shows AIR-AP1832I Ports and Connections.
Note:
|
① |
Mode button |
④ |
PoE-In port (Ethernet Uplink port) |
|
② |
RJ-45 console port |
⑤ |
48 V DC input power port |
|
③ |
USB 2.0 port |
Compare to Similar Items
Table 3 shows the comparison between two AP.
|
Part Number |
AIR-AP1832I-H-K9 |
AIRAP1832I-HK910C |
|
Description |
802.11ac Wave 2 AP, 3×3:2 |
Cisco Aironet 1830 Series 10-pack with Mobility Express, 802.11ac Wave 2 AP, 3×3:2, Internal Antenna, H Regulatory Domain ★ Model number ending in C is, by default, factory-shipped with a Cisco Mobility Express software image. |
|
Integrated antenna |
Yes |
Yes |
|
Regulatory Domain |
H (H regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.150 to 5.350 GHz; 8 channels – 5.745 to 5.825 GHz; 5 channels |
H (H regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.150 to 5.350 GHz; 8 channels – 5.745 to 5.825 GHz; 5 channels |
