The Cisco Aironet 1810 Series Access Point is vital for today’s remote workforce and micro-sites. Its strength lies in securely extending the corporate network perimeter to remote locations. The AIR-OEAP1810-E-K9 offers easy setup for non-technical users, ensuring hassle-free connectivity to enterprise resources. With 2×2 MIMO technology and two spatial streams, this AP delivers reliable, high-speed wireless connections, vital for VoIP, video conferencing, and cloud applications.
For organizations concerned with data security, the Cisco Aironet 1810 stands out with its robust layers of security protocols, including optimal encryption and secure tunneling. It supports segmented traffic, preventing cross-contamination between corporate and personal data, an essential feature for GDPR compliance and maintaining data integrity.
Ease of use is another significant benefit. The included cradle allows for desktop placement, making it fit effortlessly into any home office. With its efficient power options including PoE, this AP reduces cable clutter and allows flexibility in location and movement.
Cost savings come from the ability to utilize existing corporate resources remotely, reducing the need for expensive on-site infrastructure. By providing access to cloud services and virtualized desktops, businesses can maintain productivity levels.
In summary, the Cisco AIR-OEAP1810-E-K9 Access Point is a solid investment for organizations that prioritize security, mobility, flexibility, and productivity for their remote workforce. It’s an all-encompassing solution that caters to the needs of both the enterprise and its remote employees.
AIR-OEAP1810-E-K9, providing E Regulatory Domain, is one of the Cisco Aironet 1810 Series OfficeExtend Access Points. The 1810 Series offer a highly secure enterprise wireless and wired connection to the home, micro-branch, or other types of remote sites. The 1810 Series extends the corporate network to teleworkers, mobile workers and even micro-sites. The access points connect to the home or site broadband Internet access and establish a highly secure tunnel to the corporate network. This tunnel allows remote employees access to data, voice, video and cloud services for a mobility experience consistent with that at the corporate office. The 1810 Series supports highly secure access to corporate data and personal connectivity for teleworkers’ home devices, with segmented home traffic.
Quick Specs
Table 1 shows the quick specs of AIR-OEAP1810-E-K9.
Product Code |
AIR-OEAP1810-E-K9 |
Interfaces |
– 1 × 10/100/1000BASE-T PoE uplink port – 1 × Management console port (RJ-45) – 3 × 10/100/1000BASE-T ports (local Ethernet ports), including 1 PoE out port – 1 × DC power connector |
Features |
2×2 single-user/multiuser MIMO with two spatial streams Maximal ratio combining (MRC) 20-, 40- and 80-MHz channels PHY data rates up to 866.7 Mbps (80 MHz on 5 GHz) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Rx) 802.11 Dynamic Frequency Selection (DFS) Cyclic shift diversity (CSD) support |
Regulatory Domain |
E (E regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.180 to 5.320 GHz; 8 channels – 5.500 to 5.700 GHz; 8 channels (excludes 5.600 to 5.640 GHz) |
Integrated antennas |
– 2.4 GHz, gain 2 dBi – 5 GHz, gain 5 dBi |
System |
– 512 MB DRAM – 256 MB flash – 1.4 GHz system dual-core CPU |
Dimensions (W x L x H) |
165 x 114 x 41 mm (Access point without mounting bracket)) |
Weight |
560g (Access point without mounting bracket or any other accessories) |
Product Details
Figure 1 shows the face and left side of AP.
Note:
① |
The Face of AP |
③ |
48V DC power port |
② |
The Left side of AP |
④ |
Kensington lock slot |
Figure 2 shows the base of the AP with the ports and connectors.
Note:
① |
Console port |
④ |
LAN port 2 |
② |
Passive Pass-Through port |
⑤ |
PSE / LAN port 1 |
③ |
LAN port 3 |
· PSE / LAN port 1 provides 802.3af/at Power Sourcing Equipment (PSE) PoE-Out power on the LAN 1 Ethernet interface. With 802.3at input the PoE-Out is 6.95W (Class 2).With DC input the PoE-Out is 12.95W (Class 0).
Figure 3. Mounting the AP in the Cradle.
Note:
① |
The AP |
② |
The cradle kit |
③ |
Mounting the AP in the Cradle |
· Cisco Aironet OEAP1810 series access points can be mounted on a table or horizontal surface, using the AIR-OEAP1810-CRD= cradle kit. This kit is shipped with the access point as standard and includes a back cover and an RJ-45 jumper cable. It is also separately available from Cisco as a spare.
Figure 4 shows the AIR-OEAP1810-CRD= Cradle Views.
Note:
① |
AP Status LED indication when AP is mounted in the cradle |
④ |
LAN 3 port |
② |
PSE / LAN 1 port |
⑤ |
WAN port |
③ |
LAN 2 port |
Compare to Similar Items
Table 2 shows the comparison between two AP.
Models |
AIR-OEAP1810-E-K9 |
AIR-OEAP1810-F-K9 |
Interfaces |
– 1 × 10/100/1000BASE-T PoE uplink port – 1 × Management console port (RJ-45) – 3 × 10/100/1000BASE-T ports (local Ethernet ports), including 1 PoE out port – 1 × DC power connector |
– 1 × 10/100/1000BASE-T PoE uplink port – 1 × Management console port (RJ-45) – 3 × 10/100/1000BASE-T ports (local Ethernet ports), including 1 PoE out port – 1 × DC power connector |
Regulatory Domain |
E (E regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.180 to 5.320 GHz; 8 channels – 5.500 to 5.700 GHz; 8 channels (excludes 5.600 to 5.640 GHz) |
F (F regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.745 to 5.805 GHz; 4 channels |
