Purchasing the Cisco Aironet 1832i Access Point (AIR-AP1832I-S-K9) is an investment in cutting-edge wireless technology. Key benefits include:
1. Improved Customer Experience: The robust 802.11ac Wave 2 allows for faster connections, enhancing the experience for end-users using devices such as smartphones, tablets, and laptops.
2. High-Performance: Equipped with 3×3 MIMO technology, the Access Point is capable of supporting multiple data streams for increased performance and enhanced user capacity.
3. Enhanced Coverage: With an internal antenna and a horizontal beamwidth of 360°, it delivers expansive coverage, reducing the number of APs needed and saving on infrastructure costs.
4. Future-Proof Networking: The Wave 2 standard ensures compatibility with newer device models and prepares the network for future technology advancements without the need for immediate upgrades.
5. Easy Installation and Integration: Power over Ethernet (PoE) capability makes installation simple with minimal cabling, while the access point integrates seamlessly into existing Cisco environments for ease of management.
6. Secure Access: Cisco’s renowned security features help safeguard your network from unauthorized access, providing peace of mind.
For small and medium-sized businesses looking to scale their Wi-Fi environment efficiently, the Cisco Aironet 1832i offers power combined with ease of deployment and management, making it an invaluable asset for any growing network. Buy now to provide your users with a fast, reliable wireless experience and maintain a modern, secure network.
AIR-AP1832I-S-K9 is one of the Cisco Aironet 1830 Series Access Points. Cisco 1830 AP series is ideal for small and medium-sized networks. This series supports the latest Wi-Fi standard, the 802.11ac Wave 2 standard. The 1830 Series extends support to a new generation of Wi-Fi clients, such as smartphones, tablets, and high-performance laptops that have integrated 802.11ac Wave 1 or Wave 2 support. The model AIR-AP1832I-S-K9 provides S Regulatory Domain and internal antennas.
Quick Specs
Table 1 shows the quick specs of AIR-AP1832I-S-K9.
|
Part Number |
AIR-AP1832I-S-K9 |
|
Description |
802.11ac Wave 2 AP, 3×3:2, Internal Antenna, S Regulatory Domain |
|
Features |
– 3×3 MIMO with two spatial streams, single-user or multiuser MIMO – MRC – 802.11ac beamforming (transmit beamforming) – 20-, 40-, and 80-MHz channels – PHY data rates up to 867 Mbps (80 MHz in 5 GHz) – Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) – 802.11 DFS – CSD support |
|
Regulatory Domain |
S (S regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.180 to 5.320 GHz; 8 channels – 5.500 to 5.700 GHz; 11 channels – 5.745 to 5.825 GHz; 5 channels |
|
Integrated antenna |
– 2.4 GHz, gain 3 dBi, internal omni, horizontal beamwidth 360° – 5 GHz, gain 5 dBi, internal omni, horizontal beamwidth 360° |
|
Interfaces |
– 1 x 10/100/1000BASE-T autosensing (RJ-45), Power over Ethernet (PoE) – Management console port (RJ-45) – USB 2.0 (enabled via future software) |
|
Dimensions (W x L x H) |
8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) |
|
Weight |
3.12 lb (1.41 kg) |
Product Details
Figure 1 shows the AIR-AP1832I LED Indicator Position.
Note: â‘ LED indicator position
Table 2 shows the AP LED indicators’ descriptions.
|
Message Type |
LED State |
Message Meaning |
|
Association status |
Chirping Green |
Normal operating condition, but no wireless client associated |
|
Green |
Normal operating condition, at least one wireless client association |
|
|
Boot loader status |
Green |
Executing boot loader |
|
Boot loader error |
Red |
Boot loader signing verification failure |
|
Access point regulatory domain priming status |
Blinking Amber |
AP priming to a new regulatory domain by Neighbor Discovery Protocol (NDP), in progress |
|
Cycling Red, Green and off |
AP waiting to be primed |
|
|
Chirping Red |
AP primed to a wrong regulatory domain |
|
|
Operating status |
Blinking amber |
Software upgrade in progress |
|
Cycling through green, red, and amber |
Discovery/join process in progress |
|
|
Rapidly cycling through red, green, amber, and off. |
Access point location command invoked from controller web interface. |
|
|
Access point operating system errors |
Cycling through red, green, amber, and off |
General warning; insufficient inline power |
Figure 2 shows AIR-AP1832I Ports and Connections.
Note:
|
â‘ |
Mode button |
â‘£ |
PoE-In port (Ethernet Uplink port) |
|
â‘¡ |
RJ-45 console port |
⑤ |
48 V DC input power port |
|
â‘¢ |
USB 2.0 port |
Compare to Similar Items
Table 3 shows the comparison between two AP.
|
Part Number |
AIR-AP1832I-S-K9 |
AIR-AP1832I-S-K9C |
|
Description |
802.11ac Wave 2 AP, 3×3:2 |
802.11ac Wave 2 AP, 3×3:2 ★ Model number ending in C is, by default, factory-shipped with a Cisco Mobility Express software image. |
|
Integrated antenna |
Yes |
Yes |
|
Regulatory Domain |
S (S regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.180 to 5.320 GHz; 8 channels – 5.500 to 5.700 GHz;, 11 channels – 5.745 to 5.825 GHz; 5 channels |
S (S regulatory domain): – 2.412 to 2.472 GHz; 13 channels – 5.180 to 5.320 GHz; 8 channels – 5.500 to 5.700 GHz;, 11 channels – 5.745 to 5.825 GHz; 5 channels |
