Choosing the HPE ProLiant DL580 Gen9 Server (HPE-816821-S01) means investing in a robust and reliable compute solution that’s tailor-made for crucial enterprise applications. As an enterprise-standard x86 server, it boasts commanding performance levels critical for business intelligence, database applications, and highly virtualized environments. You benefit from superior processing power with Intel Xeon E7-4800/8800 v4/v3 processors and up to 6 TB of scalable memory, allowing for efficient handling of workload-intensive processes and simultaneous operations.
Increased I/O bandwidth from nine PCIe Gen 3.0 slots ensures that data flows smoothly and quickly, crucial for real-time analytics and other data-heavy tasks. The server’s rigorous security and data protection features ensure system resiliency, keeping your business’s sensitive information secure. In the face of demanding requirements, the reliability of this server cannot be overstated; it’s designed to minimize downtime and maximize uptime.
The inclusion of HPE OneView and HPE iLO4 for automated management grants you unprecedented control over your infrastructure, streamlining operations, and reducing the need for manual intervention. This intelligent automation translates to cost savings, making your infrastructure more agile and less expensive to manage.
Durability is also a top feature. The DL580 Gen9’s rigorous build quality means it is a long-term investment that can handle the rapidly evolving demands of enterprise environments. Moreover, its scalability means that as your business grows, the DL580 Gen9 can grow with you, adapting to new challenges with minimal additional investment.
Choose the HPE ProLiant DL580 Gen9 Server for a combination of powerhouse performance, unwavering reliability, and smart, scalable management—a definitive solution for your enterprise’s critical needs.
The HPE ProLiant DL580 Gen9 Server is the 4S enterprise standard x86 server offering commanding performance, rock-solid reliability and availability, and compelling consolidation and virtualization efficiencies. HPE-816821-S01 Supporting Intel® Xeon® E7-4800/8800 v4/v3 processors, the DL580 Gen9 Server offers enhanced processor performance, up to 6 TBs of memory, greater IO bandwidth (9 PCIe Gen 3.0 slots). The DL580 Gen9 Server has security and data protection features for system resiliency that your business can depend on. All, making it ideal for mission-critical enterprise, business intelligence, and database applications. Whether needed for highly virtualized or cloud based deployments, with intelligence and simplicity of automated management with HPE OneView and HPE iLO4 your business can achieve agile and lower cost infrastructure management.
Quick Specs
Figure 1 shows the appearance of HPE 816821-S01.
Table 1 shows the Quick Specs of HPE 816821-S01.
|
Product Code |
HPE-816821-S01 |
|
Processor |
|
|
Number of processors |
2 |
|
Processor core available |
22 |
|
Processor cache |
55MB L3 |
|
Processor speed |
2.2GHz |
|
Form factor (fully configured) |
4U |
|
Form factor chassis |
Rack |
|
Product dimensions (H x W x D) |
6.88 x 17.48 x 29 in |
Product Details
Figure 2 shows the front view of HPE 816821-S01.
Note:
|
â‘ |
CPU Memory Drawer Handle |
|
â‘¡ |
Quick removal access panel |
|
â‘¢ |
Drive bays 6-10 |
|
â‘£ |
Systems Insight Display |
|
⑤ |
Health Status LED |
|
â‘¥ |
Power On/Standby button and system power LED button |
|
⑦ |
NIC status LED |
|
⑧ |
UID button |
|
⑨ |
Fans 1-4 |
|
â‘© |
Drive bays 1-5 |
|
⑪ |
Discovery services connectors |
|
â‘« |
Video connector |
|
⑬ |
USB connectors (2) |
Figure 3 shows the ports and slots on the back panel of HPE 816821-S01.
Note:
|
â‘ |
Serial connector |
|
â‘¡ |
Video connector |
|
â‘¢ |
Power Supplies 1-4 |
|
â‘£ |
PCI expansion slots 1-9 |
|
⑤ |
Dedicated iLO connector |
|
â‘¥ |
FlexibleLOM ports 1-4 |
|
⑦ |
USB connectors (4) |
Figure 4 shows the inside view of HPE 816821-S01.
Note
|
â‘ |
CPU Memory Drawer |
|
â‘¡ |
Memory Cartridges 1-8 |
|
â‘¢ |
Processors 1-4 |
|
â‘£ |
FBWC capacitor slots 1-4 |
|
⑤ |
I/O Card Auxiliary Power Connectors |
|
â‘¥ |
Power Supplies |
|
⑦ |
PCI expansion slots 1-9 |
|
⑧ |
Flexible LOM connector |
|
⑨ |
SPI board (houses iLO chip, FBWC, microSD slot, 2x USB slots, TPM, top SAS backplane connector) |
|
â‘© |
MicroSD Slot |
The Accessories
Table 2 shows the recommended elements for the HPE 816821-S01.
|
Product number |
Model |
Description |
|
E7Y63A |
E7Y63A – Storage Networking for HPE Server |
HPE StoreFabric 84E 4-port 8Gb Fibre Channel Host Bus Adapter |
|
726724-B21 |
726724-B21 – Enterprise Memory for HPE Server |
HPE 64GB (64GB) Quad Rank x4 DDR4-2133 CAS-15-15-15 Load Reduced Memory Kit |
|
825111-B21 |
825111-B21 – Networking Adapters for HPE Server |
HPE InfiniBand EDR/Ethernet 100Gb 2-port 840QSFP28 Adapter |
|
794525-B21 |
794525-B21 – Networking Adapters for HPE Server |
HPE FlexFabric 10Gb 2-port 556FLR-T Adapter |
|
727054-B21 |
727054-B21 – Networking Adapters for HPE Server |
HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter |
|
727055-B21 |
727055-B21 – Networking Adapters for HPE Server |
HPE Ethernet 10Gb 2-port 562SFP+ Adapter |
Compare to Similar Items
Table 3 shows the comparison between HPE 816821-S01 and HPE 793310-B21.
|
Model |
816821-S01 |
793310-B21 |
|
Processor |
|
Intel® Xeon® E7-4850 v3 (14 core, 2.2 GHz 35MB 115W) |
|
Number of processors |
2 |
2 |
|
Processor core available |
22 |
14 |
|
Processor cache |
|
35MB L3 |
|
Processor speed |
|
2.2GHz |
